Carver M-1.0t (non-inverting model) troubleshooting guide

FREE shipping

29 years of electronics experience condensed to 15 pages. Includes a comprehensive theory of operation section, which explains how the amplifier works, as well as a complete troubleshooting guide.

Also available; a half-complete version of the M-500t troubleshooting guide. This guide contains a theory of operation section, which describes normal behavior, and a half-complete troubleshooting guide.

If one is familiar with carver magnetic field amplifiers, the troubleshooting guide blanks can be 'filled in' with the accompanying M-1.0t guide this product doesn't qualify for reward points or the 20% off maitriNEW coupon code; those features are reserved for maitri SPA returning customers.

Manufacturer: ZeroPointe

Free shipping

please choose a type *

M-1.0t (non-inverting) only
M-1.0t (non-inverting) AND M-500t (partially complete [+$10.55]

$21.10

Qty:

M-1.0t (non-inverting) troubleshooting guide table of contents:

Technical description
Primary circuit and regulator
Startup sequence
Power supply regulation
Load regulation
Secondary voltages
Amplifier stage
Power supply commutators
Protection circuitry
Over Current:
DC offset:
HEATSINK abnormally high temperature:
Display Board
Troubleshooting Guide
Power Supply or output?
Isolating the Power Supply from the rest of the stages
The usual suspects
Applying power to the stages
Half-split method
Half-split 1:
Half-split 2a:
Input board:
Bias network:
Half-split 2b:
Power supply
Normal indications
Usual suspects
Triac phase angle control
Half-split 1:
Half-split 2a:
Half-split 2b:
